2026 KTM 690 SMC R
2026 KTM 690 SMC R for Sale at Moorooka KTM in Moorooka, QLD | Specifications and Review Information
STOP GROWING UP
The KTM 690 SMC R obliterates the competition, proving itself as the undisputed king of its class. Providing the rider with agile handling, best-in-class power, and rider focused ergonomics, the KTM 690 SMC R embodies the notion of READY TO RACE with 110% dedication to its craft. From sliding into corners, power-wheelies over crests, and hard blasts through tight mountain passes, the King of supermoto for the street is on the attack.
Adjustablity
Finding the perfect setup when attacking tight apexes is easy, thanks to the KTM 690 SMC R's fully adjustable suspension, brake and clutch levers, and footrests - not to mention a complete PowerPart catalog filled with performance and style enhancing add-ons.
TFT Display & Connectivity
A 4.2" H42 TFT dashboard takes prime position ahead of the rider, featuring a unique, specially-designed user interface to suit the compact screen size. Made from bonded glass, the TFT screen also boasts a special coating and polarization to reduce glare and increase visibility in all lighting conditions. Riders can also access music, incoming calls, turn-by-turn navigation, and Ride Modes via the dashboard - complete with a USB port for device charging duties.
Bodywork
With an ergo triangle specifically designed to cater to everything from fast corners to casual commutes, the KTM 690 SMC R boasts aggressive, slim bodywork. This has been perfectly styled to allow for easy transitions between riding on the street and the odd dirt section. The bodywork is also made from proven, flexible, and long-lasting PP plastic material that is better suited for supermoto and aggressive riding.
Engine
-
Design
1-cylinder, 4-stroke engine
-
Displacement
692.7 cm³
-
Power
79 PS
-
Torque
73 Nm
-
Transmission
6-speed
-
CO2 emissions
96 g/km
-
Cooling
Liquid cooled
-
Engine cylinder
Single cylinder
-
EMS
Keihin EMS with RBW, twin ignition
-
Engine oil
Motorex Power Synth SAE 10W-50
-
Engine stroke
4-Stroke
Chassis
-
Front suspension
WP APEX 48
-
Rear suspension
WP APEX with Pro-Lever linkage
-
Brake disc diameters (front/rear)
300 / 240 mm
-
Front brake
Disc brake
-
Rear brake
Disc brake
-
Chain
520 X-Ring
-
Frame design
Chromium-Molybdenum steel trellis frame, powder coated
-
Front suspension adjustment
Compression and rebound adjustable
-
Silencer
Stainless steel primary and secondary silencer
-
Steering head angle
63.6°
-
Rear subframe design
Self-supporting plastic tank
-
Trail
110 mm
-
Wheelbase
1476 mm
Suspension
-
Front suspension
WP APEX 48
-
Rear suspension
WP APEX with Pro-Lever linkage
-
Suspension travel (front)
224 mm
-
Suspension travel (rear)
240 mm
-
Front suspension adjustment
Compression and rebound adjustable
-
Rear suspension addition
Preload adjuster
Dimensions
-
Seat height
899 mm
-
Wheelbase
1476 ± 15 mm
-
Tank capacity (approx.)
13.3 l
-
Ground clearance
237 mm
-
Weight (without fuel)
153.5 kg
-
Weight fully fueled
162 kg
-
Wheelbase tolerance
15 mm
-
Front wheel diameter
17"
-
Rear wheel diameter
17"
-
Front wheel width
3.5"
-
Rear wheel width
5"
-
Wheels
3.5 × 17"; 5 × 17"
The illustrated vehicles may vary in selected details from the production models and some illustrations feature optional equipment available at additional cost. All information concerning the scope of supply, appearance, services, dimensions and weights is non-binding and specified with the proviso that errors, for instance in printing, setting and/or typing, may occur; such information is subject to change without notice. Please note that model specifications may vary from country to country.The consumption values stated refer to the roadworthy series condition of the vehicles at the time of factory delivery.
